Sib npaug rau:
● Eagle Burgmann M3N/M32/M37/M37G
Kev txwv kev ua haujlwm:
● Kub: -20 degree - ntxiv rau 180 degree
● Siab: Tsawg dua los yog sib npaug rau 10bar
● Ceev: Tsawg dua lossis sib npaug li 15m / s
● Ncej Loj: 10mm - 80mm
Khoom siv:
● Foob Rings: A, B, Q1/12, Q2/22, U1/12, U2/22
● Elastomer: VITON, EPDM, NBR, FFKM, AFLAS
● Hlau Ntu: SS304, SS316, Duplex, Hastelloy C
Assembly Dwg:
Qhov Loj (mm):
| D | D3 | D13 | L22 | L23 | L3 | BT | G4 | G9 | G6 | ||||
| d7 | l3 | d7 | l3 | d7 | l3 | d7 | l3 | ||||||
| 10 | 19 | 20 | 16.9 | 15.5 | 18.1 | 5.5 | 19.2 | 6.6 | 21 | 10 | 21 | 6.6 | |
| 12 | 21 | 22 | 17.4 | 16 | 20.6 | 55.0 | 21.6 | 5.6 | 23 | 10 | 23 | 6.6 | |
| 14 | 23 | 24 | 17.4 | 16.5 | 16.5 | 23.1 | 6.0 | 24.6 | 5.6 | 25 | 10 | 25 | 6.6 |
| 16 | 26 | 26 | 19.5 | 16.5 | 18 | 26.9 | 7.0 | 28.0 | 7.5 | 27 | 10 | 27 | 6.6 |
| 18 | 29 | 31 | 20.5 | 18 | 19.5 | 30.9 | 8.0 | 30.0 | 8.0 | 33 | 11.5 | 33 | 7.5 |
| 20 | 31 | 34 | 22 | 19 | 22 | 30.9 | 8.0 | 35.0 | 7.5 | 35 | 11.5 | 35 | 7.5 |
| 22 | 33 | 36 | 23.5 | 20.5 | 21.5 | 35.4 | 8.0 | 35.0 | 7.5 | 37 | 11.5 | 37 | 7.5 |
| 24 | 35 | 38 | 25 | 22 | 23.5 | 35.4 | 8.0 | 38.0 | 7.5 | 39 | 11.5 | 39 | 7.5 |
| 25 | 36 | 39 | 26.5 | 23.5 | 26.5 | 38.2 | 8.5 | 38.0 | 7.5 | 40 | 11.5 | 40 | 7.5 |
| 28 | 40 | 42 | 26.5 | 24.5 | 26.5 | 43.3 | 9.0 | 42.0 | 9.0 | 43 | 11.5 | 43 | 7.5 |
| 30 | 43 | 44 | 25 | 24.5 | 26.5 | 43.3 | 9.0 | 45.0 | 10.5 | 45 | 11.5 | 45 | 7.5 |
| 32 | 46 | 46 | 28.5 | 28 | 28.5 | 43.3 | 9.0 | 48.0 | 10.5 | 48 | 11.5 | 48 | 7.5 |
| 33 | 47 | 47 | 28.5 | 53.5 | 11.5 | \ | \ | \ | \ | \ | \ | ||
| 35 | 49 | 49 | 28.5 | 28 | 28.5 | 53.5 | 11.5 | 52.0 | 11.0 | 50 | 11.5 | 50 | 7.5 |
| 38 | 53 | 54 | 32.2 | 31 | 33.5 | 60.5 | 11.5 | 55.0 | 10.3 | 56 | 14.0 | 56 | 9.0 |
| 40 | 56 | 56 | 34.7 | 34 | 36 | 60.5 | 11.5 | 58.0 | 10.8 | 58 | 14.0 | 58 | 9.0 |
| 43 | 59 | 59 | 38.5 | 60.5 | 11.5 | 62.0 | 12.0 | 61 | 14.0 | 61 | 9.0 | ||
| 45 | 61 | 61 | 39.2 | 36.5 | 39.5 | 65.5 | 11.5 | 64.0 | 11.6 | 63 | 14.0 | 63 | 9.0 |
| 48 | 64 | 64 | 44.7 | 42 | 46 | 65.5 | 11.5 | 68.4 | 11.6 | 66 | 14.0 | 66 | 9.0 |
| 50 | 66 | 66 | 45.7 | 43 | 45 | 72.5 | 11.5 | 69.3 | 11.6 | 70 | 15.0 | 70 | 9.5 |
| 53 | 69 | 69 | 47 | \ | \ | \ | \ | 73 | 15.0 | 70 | 9.5 | ||
| 55 | 71 | 71 | 49 | 47 | 49 | 72.5 | 11.5 | 75.4 | 13.3 | 75 | 15.0 | 75 | 11.0 |
| 58 | 76 | 78 | 52 | 50 | 55 | \ | \ | 78.4 | 13.3 | 78 | 15.0 | 78 | 11.0 |
| 60 | 78 | 79 | 53 | 51 | 55 | 79.3 | 11.5 | 80.4 | 13.3 | 80 | 15.0 | 80 | 11.0 |
| 63 | 83 | 83 | 55 | \ | \ | \ | \ | 83 | 15.0 | 83 | 11.0 | ||
| 65 | 84 | 85 | 54.3 | 52 | 55 | 84.5 | 11.5 | 85.4 | 13.0 | 85 | 15.0 | 85 | 11.0 |
| 68 | 88 | 88 | 55.3 | 52.7 | 55 | \ | \ | 91.5 | 13.7 | 90 | 18.0 | 90 | 11.3 |
| 70 | 90 | 90 | 56.3 | 54 | 57 | 89.5 | 11.5 | 92.0 | 13.0 | 92 | 18.0 | 92 | 11.3 |
| 75 | 98 | 98 | 56.3 | 54 | 62 | 3.9 | 11.5 | 99.0 | 14.0 | 97 | 18.0 | 97 | 11.3 |
| 80 | 100 | 103 | 59.3 | 58 | 61.8 | 99.5 | 11.5 | 104 | 15.0 | 105 | 18.2 | 105 | 12.0 |
UT-M37/M3N nta txhim khu kev qha kev ua tau zoo, dav daim ntawv thov ntau thiab yooj yim installation. Vim muaj kev xaiv nthuav dav ntawm cov ntaub ntawv, lawv tuaj yeem siv rau hauv cov xwm txheej sib txawv. Lub UT-M37 / M3N yog lub tshuab foob nrog lub caij nplooj ntoos hlav conical thiab lub log thawb qws tsim los rau ntau lawm. Haum rau papermaking, qab zib, tshuaj, roj av, khoom noj khoom haus, dej phwj tuaj kho thiab lwm yam lag luam.
