Kev txwv kev ua haujlwm:
● Kub: -40 ℃ - +120 ℃
● Siab: ≤ 15bar
● Ceev: ≤ 20m / s
● Ncej loj: 25mm - 100mm
Cov ntaub ntawv:
● Seal Rings: Resin Carbon, Antimony Carbon, SIC, SSIC, Tungsten Carbide
● Elastomer: FKM, FFKM, EPDM, AFLAS, NBR
● Hlau Tshooj: SS304, SS316, Duplex, Hastelloy C, 904L
Assembly Dwg:
*Kev Taw Qhia Txog *
904L (N08904, 14539) super austenitic stainless hlau muaj 14.0-18.0% chromium, 24.0-26.0% nickel, thiab 4.5% molybdenum. 904L super austenitic stainless hlau yog cov pa roj carbon tsawg, high-nickel, molybdenum austenitic stainless thiab acid-resistant steel, uas yog cov khoom siv los ntawm Fabkis H·S. Nws muaj kev ua kom zoo-passivation transformation muaj peev xwm, zoo heev corrosion kuj, zoo corrosion kuj nyob rau hauv non-oxidizing acids xws li sulfuric acid, acetic acid, formic acid, thiab phosphoric acid, thiab zoo corrosion kuj nyob rau hauv nruab nrab chloride-muaj xov xwm Nws muaj zoo pitting. corrosion kuj thiab zoo kuj rau crevice corrosion thiab kev nyuaj siab corrosion. Nws yog tsim rau sulfuric acid ntawm ntau yam concentrations hauv qab no 70 ° C. Nws yog resistant rau acetic acid ntawm tej concentration thiab kub nyob rau hauv ib txwm siab, thiab corrosion kuj nyob rau hauv cov sib xyaw acid ntawm formic acid thiab acetic acid kuj zoo heev.
Lub cev thiab mechanical zog:
Qhov ceev: 8.0g / cm3. Tensile zog: σb≥520Mpa. Elongation: ≥35%.
